CC1 Pro

Cleaning         0.3m/s      0.4m/s           0.5m/s          0.6m/s           0.7m/s              0.8m/s

  mode

Sweeping     480-530     640-690         810-860        860-960        910-1060          1000-1200

    ㎡/h

Scrubbing     270-320      360-410        450-500        500-600         550-700              600-800

   ㎡/h

Silent Dust     380-530   510-560         640-690         690-790         740-890             800-1000

Mopping

  ㎡/h

Vacuuming    450-500    600-650         760-810        810-910        860-1010          900-1100

㎡/h

Cleaning         gear level        0.3m/s        0.4m/s         0.5m/s         0.6m/s        0.7m/s        0.8m/s

 mode

                         High                 920              1230             1540            1850            2160           2460

Sweeping       Medium            970             1290             1620            1940              2260          2590

                          Low               1160             1550            1940             2330               2720          3110

                         High                  660              880             1110            1330               1550           1770

Scrubbing       Medium           860             1150            1430            1720                2010           2300

                         Low                 1010            1350            1690             2020                2360           2700

                          High                440            580                730               880                 1020            1170

   Carpet         Medium            570            760                950               1140               1330            1520

vacuuming      Low                 830            1110             1380             1660                1940             2210

                       High                1940           2590               3240           3880                4530              5180

Silent Dust   Medium          2330            3110              3880           4660                 5440              6220

  Mopping      Low                2330           3110               3880           4660                 5440              6220

gear level              0.3m/s              0.4m/s            0.5m/s            0.6m/s            0.7m/s           0.8m/s

High                       540 ㎡                720 ㎡             900 ㎡            1070 ㎡          1250 ㎡         1430 ㎡

Medium                 810 ㎡              1080 ㎡          1350 ㎡            1620 ㎡          1890 ㎡         2160 ㎡

Low                      1290 ㎡              1720 ㎡          2160 ㎡            2590 ㎡          3020 ㎡         3450 ㎡

Containers                                                                      quantitative (science)

Detergent bottles                                                                     1.5L

Dust Box/Water Filter Box                                                      2.5L

Expanded Dust Bag                                                                    6L

Standard Waste Bin                                                                 0.5L

Expandable trash can                                                              1.2L

Fresh water/sewage tanks                                                  15L/15L

Mobile water station fresh water/sewage tank                30L/30L

1. Garbage types: peanuts, melon seed shells, oatmeal, nut granules

(requires multiple cleanings).

2、Garbage Size:

Soft waste: Maximum sweeping height 30mm

Hard waste Maximum sweeping height 17mm

operating state                      cross a barrier                      cross a ravine                     climb a slope

Non-clean operation                  20mm                                      35mm                                      8°

Clean running                              8mm                                        20mm                                      3°

Conditions of use                                                                                 Specification

PH value                                              Support 6-8, recommend 6.5-7.5

foam                                                    Recommended to use non-foaming or less-foaming cleaners,

                                                               or add defoamer

Conditions of use                                                                                 Specification

PH value                                              Support 6-8, recommend 6.5-7.5

Foam                                                    Recommended to use non-foaming or less-foaming cleaners,

                                                               or add defoamer

Prohibited types of use 1. prohibited containing limonene components of the cleaner, will react

                                                chemically with plastic.

                                           2. can not use organic active cleaner, will produce flocculent, leading to

                                                clogging of the drain, and not easy to be cleaned.

1. Can be, but the hot water can not exceed 50 ℃. Because the water tank material is LLDPE, the temperature is too high will lead to deformation of the water tank.

2. Do not recommend the use of hot water: after our test found that the hot water after the whole long waterway, from the water tank out, has been cooled, the temperature difference with room temperature water is very small. Therefore, there is no difference between using hot water and cold water, just use normal cold water.

Sensor type          angle of view              Detection distance range           high degree         angle

laser radar           Horizontal 220°              5cm-40m (positioning)                                          SLAM

                                                                        5cm-4m (perception)                   /                          and

                                                                                                                                                       Perception

Rear view single            /                                 6cm-30cm                                  /           Reverse-specific

  line LIDAR

Ultrasonic           Horizontal 50°                     2cm-3m                                     /              Near Obstacle

  Sensor                 Vertical 50°                                                                                                 Detection

Downward         Horizontal 75°                   0.1m-0.9m                      0.03-0.39m           ground barrier

   RGBD                Vertical 50°                                                                                                 recognition

Up RGBD         Horizontal 75°

                         Vertical 50°                         0.1m-2.0m                        0.26-1.3m       airborne obstacle

                                                                                                                                               recognition

Product type                                         Specific parameters

CC1                                                                    100W

CC1 2025&CC1 Pro                                          200W

200-600 rpm

Brush holder pressure to ground 15kg

Maximum negative pressure (suction outlet position): 18kpa

The maximum flow rate of the CC1 suction pipe (100% in high gear) is 12L/s.

The maximum suction capacity of the fan alone (without piping) is 31.02L/s, which is equivalent to approximately

65.754 CFM.

product type                                                            Specific parameters

CC1                                                                              50-300ml/min

CC1 2025&CC1 Pro                                                   50-500ml/min
